Completed Job Report

Job reference
JOB-002

Heat Discolouration at Terminal

Riverside Business Centre · 88 River Rd, Parramatta NSW
Original issue
Visible heat discolouration and brown scorching near cable termination
AI findings
Asset: Commercial distribution board — Feeder 3. Probable issue confirmed via image analysis with 94% confidence. Severity assessed as High. Licensed electrician required.
Completed actions
Main switch isolated → proven dead → LOTO applied → failed RCBO replaced → terminations torqued → insulation & RCD trip-time tests passed → circuit relabelled.
Parts used
63A MCCB replacement, Copper lug 25mm², Torque calibration certificate
Safety checks
Isolated at main, LOTO applied, PPE worn, area cordoned, pre/post photos captured.
Compliance
Non-Compliant — AS/NZS 3000 termination integrity verified; AS/NZS 3017 test results recorded.
Electrician
Kevin Hanlon · Electrical Lic. #EC-48210 · 18 Jul 2026 10:42
Before / After verification
Before — heat discolouration at breaker terminal
BEFORE — heat discolouration at breaker terminal
After — replaced RCBO and clean terminations
AFTER — replaced RCBO & torqued terminations
